Vex 5 Outdoor Wall Sconce
DELIVERED LUMENS 554.3
WATTS 18.7
VOLTAGE Universal 120V - 277V
DIMMING 0-10V, ELV, TRAC, CL
LIGHT DISTRIBUTION Symmetric or Asymmetric depending on
barn doors position
MOUNTING OPTIONS Wall
OPTICS Adjustable beam spread
CCT 2700K
CRI 90+
COLOR BINNING 3-Step
BUG RATING B0-U3-G0
DARK SKY Non-Compliant
WET LISTED IP65
GENERAL LISTING ETL, ADA
CALIFORNIA TITLE 24
Can be used to comply with CEC 2019 Title 24 Part 6 for outdoor use. Registration with CEC Appliance Database not required.
START TEMP -30°C
FIELD SERVICEABLE LED Yes
CONSTRUCTION Aluminum
HARDWARE Stainless Steel
FINISH Powder Coat
LED LIFETIME L70; >60,000 Hours
WARRANTY* 5 years
WEIGHT 2.4 lbs.
